okay here is my story:
remember The Womb? I think it is my best diorama, there is a dry cinism about it and a sense of colour that tells me i am finally getting somewhere. BUT I don't like having to look at it, it's just too terrible, it's currently in one corner of the garden shed and i will probably dump it on ebay in 5 years time.
So i thought I needed to do something like the Womb but more my way you see, more ambient and detached. Something with a turret too. So it was years that I considered doing a diorama with one plane turret sticking out of the water but i thought that would look sort of stupid and artifical. And then a few weeks ago i fell on some Telford report ona ship forum showing a model of this:

you see? those turrets at the back of the boat? plane turrets of the most peculiar form as they are looking like some lightbulb.
So this boat nicknamed the "whaleboat" because of the dome shaped rear, was used by the British to get downed pilots in the Channel, and generations of modelers built the Airfix model with *basically no reference except an article with 5 poor quality pictures in an Airfix mag from the late 70's*
Asking questions in forums I was quickly prompted with this article alongside a set of bad quality plans done by "the great specialist of British MTBs one Mr Pritchard..
Then I was given a list of 5 absolutely unfindable books about those boats.. Looking online, I found 3 extra photos, and .. that was all.
So here I was starting my build with basically no reference about a British WW2 boat that is well known to modelers.. amazing, truly amazing. Britain i used to know you better.

I saw that Mr pritchard designed a set of good sized plans so i set up buying them but alas the deception was huge as i could find straight away some innacuracies -worse even he seems to have been designing them using some huge sized pen akin to the ones you give to kids.
he also included some cross section plans.. for the hull but not for the rounded cabin!!
All the problems induced by this third rate material will sadly show through throughout the build..

In the end I found out what those plans were for: the RC guys who probably figure out that a boat model is accurate as long as it floats.

here are the plans anyhow.. what a waste of paper..



phew what a rant, that's all for today..





jba
